L-DALI User Manual 19 LOYTEC
Version 5.2 LOYTEC electronics GmbH
o Analog Input object providing lux level information from supported DALI
sensors
o Binary Input objects providing occupancy information from supported DALI
sensors
o Loop objects providing constant light controller functionality
1.2 L-DALI Models
This Section provides an overview of the different L-DALI models in Table 1. This table
identifies the different features of the L-DALI models. Models that possess a certain feature
have a check mark () in the respective column. If a feature is not available in the particular
model, the column is left blank.
Model
Feature
3E101
3E102
3E104
3101-U
E101-U
ME204
E201-U
DALI Power Supply



DALI Channels
1
2
4
1
1
4
1
DALI Emergency Lights Test







Constant Light Controller







Sunblind Controller





Display with Jog Dial



LON TP/FT-10




LON IP-852 (Ethernet/IP)




BACnet MS/TP

BACnet/IP (Ethernet/IP)


Configuration via WEB UI






Configuration via Software







Console connector




Table 1: Available features in different L-DALI models.
Important: In the following text models with BACnet interface are referred to as LDALI-20X and
models with LONMARK/CEA-709 interface are referred to as LDALI-10X.
1.3 Scope
This document covers L-DALI devices with firmware version 5.2 and the L-INX
Configuration Software version 5.2.
