L-DALI User Manual 54 LOYTEC
Version 5.2 LOYTEC electronics GmbH
4.8.3 LDALI-E101-U and LDALI-E201-U
Terminal
Function
N, L
Power Supply 85-240 VAC 50/60 Hz
DA+, DA-
DALI Channel 1
(with internal DALI bus power 230mA)
Table 9: LDALI-E101-U and LDALI-E201-U Terminals.
Important: The LDALI-E101-U and LDALI-E201-U models come with an internal DALI bus power
supply. Thus, no additional DALI bus power supply or any other device with an internal
DALI bus power supply must be connected to the same DALI channel!
4.8.4 LDALI-3101-U
Terminal
Function
A, B
CEA-709 A, B of FT-10 Channel Port
N, L
Power Supply 85-240 VAC 50/60 Hz
DA+, DA-
DALI Channel 1
(with internal DALI bus power 230mA)
Table 10: LDALI-3101-U Terminals.
Important: The LDALI-3101-U models come with an internal DALI bus power supply. Thus, no
additional DALI bus power supply or any other device with an internal DALI bus power
supply must be connected to the same DALI channel!
4.9 Wiring
Connect the L-DALI to the DALI network as shown in Figure 5 and Figure 6. For easy
configuration, it is recommended to always connect the L-DALI to the Ethernet network (if
available).
4.9.1 LDALI-ME20X
If BACnet over MS/TP is enabled, the MS/TP network segment must be properly
terminated with an LT-04 network terminator connected at each of the two ends of the
segment media.
