L-DALI User Manual 52 LOYTEC
Version 5.2 LOYTEC electronics GmbH
Send ID messages: When selecting this menu, the device sends out service pin,
BACnet I-Am, and identification broadcasts for finding the device in the L-Config tool
on all applicable ports.
Reload config: By choosing this menu, the device performs a quick restart by
reloading its configuration only.
Reboot system: By choosing this menu, the device performs a full reboot.
Clear DP config: By choosing this menu, the user can clear the device’s entire data
point and DALI configuration. This is equivalent to the same Web UI function. The IP
address as well as other settings needed to reach the device are not deleted.
Factory Defaults: By choosing this menu, the user can reset the entire device to its
factory default. All user configuration including IP addresses are cleared.
Remote Config: When enabling this option, the LWEB-900 master device manager
restores the last saved configuration to the discovered device, if it has no configuration
yet. This feature is beneficial when replacing a device.
Change PIN: Alter the default PIN to any 4-digit number to protect certain operations
on the LCD UI. The user will be prompted to enter the PIN on protected areas.
Contrast: Allows adjusting the LCD contrast.
Language: Allow to select the language used for the LCD UI.
4.7 DIP Switch Settings
L-DALI models without LCD display are equipped with a DIP switch. The DIP switch
assignment is shown in Table 6. Please leave all switches at default state.
Table 6: DIP Switch Settings for L-DALI.
4.8 Terminal Layout and Power Supply
The L-DALI provides screw terminals to connect to the network as well as to the power
supply. The screw terminals can be used for wires of a maximum thickness of 1.5
mm
2
/AWG12.
