L-DALI User Manual 45 LOYTEC
Version 5.2 LOYTEC electronics GmbH
4 Hardware Installation
4.1 Enclosure
4.1.1 LDALI-3E10X and LDALI-ME204
The LDALI-3E10X and LDALI-ME204 enclosure is 159 mm wide for DIN rail mounting,
following DIN 43 880 (see Figure 37).
Figure 37: LDALI-3E10X and LDALI-ME204 Enclosure (dimensions in mm [inch]).
4.1.2 LDALI-E101-U, LDALI-3101-U and LDALI-E101-U
The LDALI E101 U, LDALI 3101 U and LDALI E101 U enclosure is 107 mm wide for
DIN rail mounting, following DIN 43 880 (see Figure 38).
