L-DALI User Manual 261 LOYTEC
Version 5.2 LOYTEC electronics GmbH
Figure 217: Timing of occupancy detection.
8.2.7.2 Output Network Variables
OC_NUL (-1): Invalid Value
OC_OCCUPIED (0): Area is occupied
OC_UNOCCUPIED (1): Area is unoccupied
OC_BYPASS (2): Area is temporarily occupied for the bypass period
OC_STANDBY (3): Area is temporarily unoccupied
This network variable provides the occupancy state measured by the occupancy sensor.
If no corresponding occupancy sensor is present on the DALI network the value is OC_NUL.
8.2.7.3 Configuration Properties
All configuration properties listed in this section are implemented as Configuration
Parameters using configuration files (CPT, CPV, and CPC files). File access is provided via
LONMARK FTP.
SCPTheartbeat (SNVT_time_sec)
0..6553.4 sec
Resolution: 0.1 sec
Maximum period of time that expires before the object automatically transmits the present value
of the nvoOccup output NV.
