nvoButtonState
Type
SNVT_state
Valid Range
-
Default Value
0
Description
If a button input is configured with the button function Generic the state of this input is mapped to
the corresponding bit of the SNVT_state (bit0 to input 1, bit1 to input 2, etc.). The bit is set to 1 if
the button is pressed or the contact is closed and 0 otherwise.
8.2.11.2 Philips OccuSwitch
This template has to be selected when expanding an IRT 8080 IR-remote control the Philips
OccuSwitch DALI LRM2090/20 to controlling sunblinds, fan speed, and temperature
setpoint in a room. In this case each Button object contains the following network variables:
nvoSetPtOffset
Type
SNVT_temp_p
Valid Range
-3°C to +3°C
Default Value
-
Description
This network variable output allows adjusting the HVAC setpoint by supplying an offset to a
preconfigured setpoint. Its value is controlled by the temperature setpoint button on the IRT 8080.
nvoFanSpeedCmd
Type
SNVT_switch
Valid Range
.value: 0%, 33%, 66%, 100%
.state: 0, 1
On: .state = 1 and .value > 0
Off: .state = 0 and .value=any or .state=1 and .value = 0
Default Value
-
Description
This network variable output allows control the speed of a ventilation fan. Its value is controlled
by the temperature fan speed button on the IRT 8080.
