Operating the system
ProtoMat S64/S104
108/160
LPKF Laser & Electronics AG | V. 1.0
3. Click on [Measure].
 The processing head is lowered in small steps to the material. Once the working-
depth limiter touches the surface of the material, a limit switch is triggered and the
measured value is displayed in the spin box.
If you already have acquired experience with the material and want to influence the
material removal, you can modify the measured value accordingly using the arrow
buttons of the spin box.
4. Click on [Save] to apply the measured value in the dialog Material settings.

The thickness of the material has been measured.
