LulzBot Mini User Manual

3D Printer Software
Loading a Profile
When you first switch to Full Settings, Cura will revert to very generic
settings. We recommend using our tested profiles that are available here:
https://www.lulzbot.com/support/downloads. You will want to choose
the profile that matches your filament and quality needs. Once downloaded,
you can load the file into Cura by selecting File > Open Profile. Choose
your desired profile. This will automatically update all of your settings for
use with your printer.
1.10 Basic Tab Options
Layer Height
The thickness of each printed layer is known as the Layer Height. The
smaller the layer height, the smoother curves will appear. Larger layer
heights are better for bridging and overhangs. Smaller layer heights will
also increase print time, as it will take more layers to complete the object.
Figure 1.13: Differences in Layer Height
26

LulzBot Mini Specifications

General

Tweezers	Yes
Certification	CE, FCC, WEEE
Product color	Black, Green
Viewing window	No
Maximum print platform temperature	120 °C
Package weight	11330 g
AC input voltage	100/240 V
Power consumption (typical)	150 W
Print technology	-
Printing material	ABS, HIPS, Nylon, PVA, Polycarbonate (PC), Polylactic acid (PLA)
Layer thickness (max)	0.5 mm
Layer thickness (min)	0.05 mm
Maximum build size (WxDxH)	152 x 152 x 158 mm
Filament thickness supported	3 mm
Maximum vertical build speed	275 mm/sec
Printing compartment volume	3.65 L

Weight and Dimensions

Depth	435 mm
Width	340 mm
Height	385 mm
Weight	8550 g
