LulzBot Mini User Manual

2.2. GETTING SLIC3R
2.2 Getting Slic3r
Slic3r is Free Software, and is licensed under the GNU Affero General Public
License, version 3.
Downloading
From LulzBot
The Slic3r version that has been tested for the Mini 3D printer
can be downloaded from the LulzBot.com downloads page:
https://www.lulzbot.com/support/downloads.
Pre-compiled packages are available for Windows, Mac OS X and Linux.
Windows and Linux users can choose between 32 and 64 bit versions to
match their system.
Slic3r
Slic3r can be downloaded directly from: http://slic3r.org/download.
Pre-compiled packages are available for Windows, Mac OS X and Linux.
Windows and Linux users can choose between 32 and 64 bit versions to
match their system.
Manual
The latest version of full Slic3r manual, with L
A
T
E
X source code, can be
found at: https://github.com/alexrj/Slic3r-Manual
Source
The source code is available via GitHub: https://github.com/alexrj/Slic3r.
For more details on building from source see §2.2 below.
Installing
Linux
Extract the archive to a folder of your choosing. Either:
53

LulzBot Mini Specifications

General

Tweezers	Yes
Certification	CE, FCC, WEEE
Product color	Black, Green
Viewing window	No
Maximum print platform temperature	120 °C
Package weight	11330 g
AC input voltage	100/240 V
Power consumption (typical)	150 W
Print technology	-
Printing material	ABS, HIPS, Nylon, PVA, Polycarbonate (PC), Polylactic acid (PLA)
Layer thickness (max)	0.5 mm
Layer thickness (min)	0.05 mm
Maximum build size (WxDxH)	152 x 152 x 158 mm
Filament thickness supported	3 mm
Maximum vertical build speed	275 mm/sec
Printing compartment volume	3.65 L

Weight and Dimensions

Depth	435 mm
Width	340 mm
Height	385 mm
Weight	8550 g
