Figure 4.41: Linkage Cover
5. Remove linkage cover (A) by removing bolt (B) and
rotating cover upward until inboard end can be lifted off.
Figure 4.42: Linkage Cover
NOTE:
Refer to the decal (A) inside each linkage cover.
Figure 4.43: Wing Lock in UNLOCK Position
6. Unlock the wings by moving spring handles (A) to lower
(UNLOCK) position.
