214325 128 Revision A
4.18 Lubricating Header
Table 4.5 Recommended Lubricant
Specification
Description Use
SAE multipurpose
High temperature, extreme pressure (EP2) performance
with 1% max molybdenum disulphide (NLGI Grade 2)
lithium base
As required unless
otherwise specified
High temperature, extreme pressure (EP) performance with
10% max molybdenum disulphide (NLGI Grade 2)
lithium base
Driveline slip-joints
4.18.1 Greasing Procedure
Greasing points are marked on machine by decals showing a grease gun and grease interval in hours of operation.
Master grease point location decals are provided on header and adapter back frame.
DANGER
To avoid bodily injury or death from unexpected start-up of machine, always stop engine and remove key
from ignition before leaving operator’s seat for any reason.
Figure 4.77: FD75 Master Grease Point Decal
PERFORMING PREDELIVERY CHECKS
