Figure 4.70: Drive Roller
4. Check that draper guide (rubber track on underside of
draper) is properly engaged in groove (A) of drive roller.
Figure 4.71: Idler Roller – Typical Both Ends
of Roller
5. Check that idler roller (A) is between guides (B).
PERFORMING PREDELIVERY CHECKS
