214683 186 Revision A
Figure 3.283: Header Settings
4. To specify the type of header installed on the machine,
touch the HEADER TYPE field (A).
Figure 3.284: Header Type
5. A list of predefined header types appears.
• For MacDon D1 Series Draper and FD1 Series
FlexDraper headers, touch POWER FLOW (A)
• Touch the green check mark (B) to save the
selection and continue
Figure 3.285: Header Settings
6. Make sure that the HEADER HAS REEL ATTACHED
check box (A) is checked.
OPERATION
