214683 305 Revision A
Figure 3.543: Attaching Tow-Bar
12. Position the tow-bar (A) onto the axle, and push against
the latch (B) until the tow-bar pins drop into the
hooks (C).
13. Check that latch (B) has engaged the tow-bar.
14. Install the clevis pin (D) and secure with hairpin.
Figure 3.544: Harness Connection
15. Connect the electrical harness (A) at the front wheel.
OPERATION
