Table 2.1 Header Specifications (continued)
Draper speed: FM100 Float Module controlled
0–193 m/min. (635 fpm) S
PR15 Pick-Up Reel
Quantity of tine tubes
5-, 6-, or 9-tine tubes
Center tube diameter 203 mm (8 in.) S
Finger tip radius Factory-set
800 mm (31-1/2 in.) S
Finger tip radius Adjustment range
766–800 mm
(30-3/16–31-1/2 in.)
S
Effective reel diameter (via cam profile) 1.650 m (65 in.) S
Finger length
290 mm (11 in.) S
Finger spacing (staggered on alternate bats) 150 mm (6 in.) S
Reel drive Hydraulic
S
Reel speed (adjustable from cab, varies with combine model)
0–67 rpm
S
Frame and Structure
Header
width
Field mode
Cut width +
384 mm (15-1/8 in.)
S
Header
width
Transport position - reel
fore-aft fully retracted
(shortest center-link)
(A) Long dividers installed
(refer to Figure 2.1, page 23)
2.684 m (106 in.)
—
Header
width
Transport position - reel
fore-aft fully retracted
(shortest center-link)
(B) Long dividers removed
(refer to Figure 2.1, page 23)
2.500 m (98 in.)
—
