Manitowoc 16000 Operator's Manual

Reference Only
SET-UP AND INSTALLATION 16000 OPERATOR MANUAL
4-22
Published 05-09-17, Control # 011-29_v2
1
1
2
1
3
8
9
7
6
View B
Both Ends of
Carbody
View C
FIGURE 4-15
Legend
Item Description
3 Lifting Lug (4 places each box)
4Slot
5Hook
6Pin
7Pin
8 Stairway (optional)
9 Pin (optional)
4-13A
A10786
5
4
View A
Carbody Counterweight Identification
Item Description
Required Each End
of Carbody
Weight Each
lbs (kg)
Total Weight
lbs (kg)
Series 1
No Carbody
Counterweight
Series 2 1Center Box 1
30,000
(13 608)
60,000
(27 216)
Series 3
1Center Box 1
30,000
(13 608)
120,000
(54 431)
2 Side Box 2
15,000
(6 804)
See Liftcrane Mast Capacities
Chart at end of this section for
detailed lifting capacities.
