Manitowoc Published 05-09-17, Control # 011-29_v2 4-77
16000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
20 Part
13 Sheave Block
22 Part
13 Sheave Block
26 Part
13 Sheave Block
24 Part
13 Sheave Block
LOWER BOOM
POINT REEVING
12 Part
9 Sheave Block
14 Part
9 Sheave Block
16 Part
9 Sheave Block
18 Part
9 Sheave Block
Reeving_2
FIGURE 4-49 continued
