SET-UP AND INSTALLATION 16000 OPERATOR MANUAL
4-78
Published 05-09-17, Control # 011-29_v2
FIGURE 4-50
EXTENDED BOOM POINT REEVING
(Lower Sheaves)
Item Description
1 Boom Top Guide Sheaves
2 Extended Upper Boom Point
(lower sheaves)
3 Load Block
Dead-End Socket
Two-Block Weight
3
6 Part2 Part 4 Part
2
1
Reeving_3
