Scala | V7 | Display Configuration
Procedure
1.
From the lower part of the control panels, click Customize.
The Customize panel appears.
2.
Click + drag the TS 3D to the page.
3.
Drop it in a yellow area.
4.
In the dialog box that appears, select the location of the trawl speed sensor.
The 3D view of the trawl speed sensor is displayed. You can see the along and across speeds and
the positioning angle of the trawl.
What to do next
When you have finished customizing pages, you need to deactivate the Customize mode: click
Menu > Customize again.
| 104
