Scala | V7 | System Configuration
Results
Scantrol data are displayed in Scala.
Outputting NMEA Data to Other Systems
You can send to other systems data you receive from sensors on Scala.
Procedure
1.
Click Menu > Settings.
2.
In the NMEA Outputs tab, click Add.
3.
Choose the type of connection between serial port, UDP or TCP socket.
4.
Enter the output parameters.
• Serial port: select the name of the port and baud rate of the device.
• UDP: enter the port number from which data are broadcast. Then, click the interface menu to
select the IP address of the connected device (refer to your network preferences).
Note: The logical network interface (such as en0, en1) associated with the IP
addresses differs from one computer to another. If doing the same installation on
another computer, do not enter the same interface on purpose.
• TCP: enter the port number from which data are sent.
5.
Under the Data to Emit tab, select which data you want to output:
• The first two options output data that are received on Scala from Marport sensors.
•
Select Emit trawl positioning sentence if you need to send positioning data to another
system (such as a cartography software) and choose the sentence corresponding to this
system.
| 43
