Scala | V7 | System Configuration
Types of Filters
This table shows the filters available, as well as dependencies when some filters are set as active (in
some cases they work in combination).
Data Filters
Filter Definition Filters Also Active
Min/Max
Removes data that is too high and not coherent
with the maximum conditions of the vessel. This
filter is particularly useful for depth or spread
data.
None by default, but you
can also select Rate of
Change, Some Smoothing
and More Smoothing in
Advanced tab.
Rate of Change
Applies a limit of how fast data can change
when sent and displayed on the user interface. It
removes incoherent variations. It is useful on all
data.
Min/Max
Some
Smoothing
Smoothens data and prevents jumps in the display.
This can add some delay to the information
displayed. This filter is particularly useful on
pitch/roll, spread, depth.
It uses a Median filter to remove acoustic
communication errors, and a Low-Pass filter to
smoothen the form of the signal.
Min/Max, Rate of Change
More
Smoothing
Filters at higher grade than Some Smoothing.
Creates more delay and detail in data may be lost.
Min/Max, Rate of Change
Debounced
2/3/4
Only for catch sensors. Displays catch status as
full when receiver has received 2, 3 or 4 "full"
signals from catch sensor. You can also choose no
filtering.
-
The picture below shows incoherent and erratic data being received:
| 33
