Scala | V7 | Display Configuration
Procedure
1.
To zoom in and out of the distance scale, place your cursor on the vertical axis of the echogram
or history plot and scroll.
2.
To zoom in and out of the time stamp, place the cursor on the horizontal axis and scroll.
Note: When two echograms or two history plots are displayed one above the other, they
have the same time stamp. So if you zoom on one, the other will also zoom. If you do not
want the echograms to be synchronized, place them side by side.
3.
To move along the time stamp or distance scale, click + drag the scale.
4.
To come back in the time stamp to data currently being received, click the arrow on the right.
| 92
