Masimo Root User Manual

Root NIBPT Chapter 3: Operation
www.masimo.com 72 Masimo
Option Description Factory
Default
Setting
Configurable
Settings
Save as
Pediatric
Saves current profile
parameter as the Pediatric
Profile.
N/A
Press Save to
update the profile.
Save as Neo
Saves current profile
parameter as the Neonatal
Profile.
N/A
Press Save to
update the profile.
Factory Defaults
Options are restored to
factory value.
N/A Press Restore.
*Changes to USB Ports baud rate will take effect after Root is power cycled, turned off then on
again.
Note: Restore Factory Defaults can only be performed during non-monitoring and no cable
connections are present.
Device Output
The Device Output screen allows the user to configure additional data output options. A Nurse
Call can be triggered based on alarm, low Signal IQ events or both. In addition, Nurse Call
Polarity can be inverted to accommodate local Nurse Call station requirements.
Option Description Factory
Default
Setting
Configurable
Settings
Nurse Call
Trigger
Controls the source of monitoring
which sets off the trigger.
Alarms
Alarms, Low SIQ,
Alarms + SIQ
Nurse Call
Polarity
Controls the mechanism of action for
triggering to occur. Should be changed
to accommodate institutional Nurse
Call settings.
Normal Normal or Inverted
USB Port 1 Controls the output type for USB Port 1. None
None, SatShare,
ASCII 1,
IntelliBridge, or IAP

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
