TECHNICAL DATA11 - 9
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
* see
Menu 1y.5.2 Actuator, page7-41
** The maximum possible mains power voltage on the D-MAXE
Controller is 51VDC. The D-MAXE Controller regulates the
voltage down to the necessary level required by the
connected motor/valve.
*** 1.3A is used for the 1.6A motor.
Display content* Current
**Nom.
voltage
Motor/Valve ID Typical modules
1.0A MOTOR 44.2K 1.0A 48 VDC
M352559 Motor
M352560 Motor
44.2K NarroWeb 50
50mA HYDR 64.9K ±50mA 24 VDC
Hydraulic
proportional valve
64.9K
48V LVALVE 78.7K 0.6A 48 VDC
Hydraulic
proportional valve
and
48 V locking valve
78.7K
24V LVALVE 95.3K 1.2A 24 VDC
Hydraulic
proportional valve
and
24 V locking valve
95.3K
50mA HYDR AXC
121K
±50mA 24 VDC
Hydraulic servo-
valve
121K
Zero-overlapped
valve
48V LVALVE AXC
154K
0.6A 48 VDC
Hydraulic servo-
valve
154K
Zero-overlapped
valve with 48V
locking valve
24V LVALVE AXC
205K
1.2A 24 VDC
Hydraulic servo-
valve
205K
Zero-overlapped
valve with 24V
locking valve
10mA MPA 287K ±10mA 24 VDC MPA Motor driver 287K MPA-01/-02/-30
CUSTOM MTR 825K Adjusted motor 825K
Not a motor from
Fife
_ No motor or valve detected. None
