CONTROLLER MENUS: 1Y.5 HARDWARE IOS 7 - 41
D-MAXE with OI-B/OI-Nwww.maxcessintl.com MI 2-296 1 D
Prozessor bedienung.fm
Additional menus 1y.5._ This section contains a list of menus with information about
connected input/output devices of the D-MAXE Controller.
Menus
Key sequence for menus:
Menu 1y.5.2 Actuator
Display of the motor connected to the selected drive
see
Actuators, page 11-8
Menu 1y.5.3 Digital Inputs
Display of the 6 digital inputs as binary value
In the following submenus you can tell which of the inputs are
activated or not activated. Activated inputs appear marked in
the list.
1y.5._
→ Select the desired menu
