CONTROLLER MENUS: 1Y.5 HARDWARE IOS7 - 26
D-MAXE with OI-B/OI-N www.maxcessintl.comMI 2-296 1 D
Menu 1y.5.1.1.4
Sensor Supervision
Description You can use the Sensor Supervision menu to turn this parameter
on and off.
The parameter is used to detect a faulty connection between the
D-MAXE Controller and a connected sensor. This parameter can
only be evaluated if corresponding customer-specific
programming is present.
The following explanation of menus is based on the example of
the S01 sensor connected to X5/1.
Menu
 Key sequence for menu 1y.5.1.1.4:
The current setting for the Sensor Supervision parameter is
shown.
 Enable the parameter for input
Input
Menu 1y.5.1.1.4.1:
Sensor Supervision
 Select the desired entry in the list
 Save the entry or cancel
1y.5
→ Hardware IOs
or
1y.5.1
→ Sensor Setup
or
1y.5.1.1
→ S 01
or
1y.5.1.1.4
→ Sensor Supervision
or
...
...
or
or
