Menu 1y.5.1.7.1
Calibration
WARNING:
The selected drive must be moved to calibrate the encoder.
This involves the risk of being cut on the web.
There is a danger of body parts being crushed against the
actuator.
CAUTION:
Changing the encoder limits may result in danger of crushing or
could damage the mechanical stops.
Description You can use the
Encoder menu to calibrate a connected position
transducer (encoder) for the selected drive. The Servo-Center
transducer assigned to this drive determines the reference
position of the travel path.
The following explanation of menus is based on an example of
the encoder connected to X3.
Note:
The Servo-Center transducer must be positioned within the
restricted travel path before it is possible to approach the
Servo-Center position in "Servo-Center" mode.
