CONTROLLER MENUS: 1Y.5 HARDWA
RE
IOS
7 - 33
D-MAXE with OI-B/OI-N
www.maxcessintl
.com
MI 2-296 1 D
Prozessor bedienung.fm
Menu
Key sequence for menu
1y.5.1.7.1:
The encoder signal current
ly present is displayed.
∙
Enable the parameter for in
put
∙
Start the sequence for calibrating the
Encoder (X3)
parameter
Menu 1y.5.1.7.1.1
1. [ENTER]
to SC
The drive first moves to th
e Servo-Center
position.
∙
Approach the Servo-Center positio
n
→
H
ardware IOs
or
1y.5
1y.5.1
→
Sensor Setup
or
1y.5.1.7
→
E
ncoder (X3)
or
...
...
1y.5.1.7.1
→
C
alibration
or
88
90
