Chapter 5 Parameters
78
P113 Digital input DI4 filter
Range
Default
value
Unit Usage
0.1～100.0 2.0 ms ALL
 DI4 input digital filtering time constant. Refer to the description of parameter P110.
P114 Digital input DI5 filter
Range
Default
value
Unit Usage
0.1～100.0 2.0 ms ALL
 DI5 input digital filtering time constant. Refer to the description of parameter P110.
P118
Digital high speed input 1 (HDI1)
filter level
Range
Default
value
Unit Usage
1~8 4 ALL
 Parameter meaning:
1~8: From low to high, the filtering ability is enhanced
P119
Digital high speed input 2 (HDI2)
filter level
Range
Default
value
Unit Usage
1~8 4 ALL
 Parameter meaning:
1~8: From low to high, the filtering ability is enhanced.
P120 Digital input DI forced valid 1
Range
Default
value
Unit Usage
00000～11111 00000 ALL
 Corresponding functions are represented by 5-bit binary:
Digital bit4 Bit3 Bit2 Bit1 bit0
Corresponding function CWL CCWL ARST SON NULL
 The function used to force DI input is valid. If the corresponding bit of the function is set
to 1, the function enforces ON (valid).
 The meaning of the DI symbol is referred to Section 5.2. Parameter meaning:
One of the parameters Corresponding functions [Note] Functional results
0
Not planned OFF
planned It depends on the input signal
1 Not planned or planned ON
Note: Planned refers to the function selected by parameters P100 ~ P104;
Unplanned is a function that is not selected by parameters P100 to P104.
P121 Digital input DI force valid 2
Range
Default
value
Unit Usage
00000～11111 00000 ALL
