Maytag MDE17CS - Remove Earth Wires Inside Collar

4-63
Remove the upper dryer (See page 4-58).
Remove the 1/4” hex head screw that
secures each Earth wire to the collar.
1.
2.
REMOVE EARTH WIRES
INSIDE COLLAR
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1/4” Hex
Head Screws
