4-68
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
Remove the dryer front panel
(See page 4-66).
Remove the belt (See page 4-31).
Grasp the front edge of the drum and slide it
out of the front of the dryer.
1.
2.
3.
REMOVE DRYER DRUM FROM STACK DRYER
NOTE: When reinstalling the drum, make
sure the plug or clip, or drum hole if the plug
or clip is missing, is to the rear of the dryer,
which is opposite of the way the drum is
installed in the single dryer.
Drum Hole With
Clip Or Plug
To Next Page
