1-11
CODE EXPLANATION
COIN/DEBIT OPTION
Both coin & debit selected. (NOT AVAILABLE)
Coins selected, debit disabled.
Press DELICATES button for this selection.
Debit Card selected, coin disabled. Default for PN models, and for
PN operation, must be set as J._d.
Press DELICATES button for this selection.
Enhanced debit is self-selected when a Generation 2 card reader
is installed in the dryer. The ‘Ed’ option cannot be manually
selected or deselected. (NOT AVAILABLE)
Press PERM. PRESS button once to advance to next code.
PRICE SUPPRESSION OPTION
This option is either SELECTED ‘ON’ OR NOT SELECTED ‘OFF’.
This option causes the customer display to show ‘AVAILABLE’ or
‘ADD’ rather than the amount of money to add. (Used mainly in
debit installations.)
Not Selected ‘OFF’.
Selected ‘ON’. Press DELICATES button once for this selection.
Press PERM. PRESS button once to advance to next code.
CLEAR ESCROW OPTION
This option is either SELECTED ‘ON’ OR NOT SELECTED ‘OFF’.
When selected, money held in escrow for 30 minutes without
further escrow or cycle activity will be cleared.
Selected ‘ON’.
Not Selected ‘OFF’. Press DELICATES button once to deselect
this option.
Press PERM. PRESS button once to advance to next code.
HUNDREDTH INCREMENT OFFSET
This represents the hundredth increment price offset used in
Generation 2 (Enhanced Debit) PN models. Choose from 0–4
hundredths by pressing the WHITES & COLORS button.
Press PERM. PRESS button once to advance to next code.
(NOT AVAILABLE)
If the set-up mode is entered and one of
the following has occurred, the appropriate
diagnostic code will be in the display.
DIAGNOSTIC CODES
If cycle counter (9 0C) is selected, the following is true:
1 00 Represents the number of cycles in HUNDREDS. 1 02
= 200
2 00 Represents the number of cycles in ONES. 2 25
= 25
TOTAL CYCLES = 225
This is ‘VIEW ONLY’ and cannot be cleared.
Press the PERM. PRESS button once to advance to next code.
If money counter (1.0C or 1.C0) is selected, the following is true:
3 00 Currency amount in HUNDREDS. 3 01 = 100.00
4 00 Currency amount in ONES. 4 68 = 68.00
57.00=575Currency amount in HUNDREDTHS. 005
TOTAL = 168.75
END OF SET-UP PROCEDURES
EXIT FROM SET-UP MODE
PD MODELS: Reinstall access door.
PN MODELS where AA1 plug was removed:
Unplug dryer or disconnect power.
Open console, reinsert jumper into AA1, close console.
Plug in dryer or reconnect power.
PN MODELS: Turn key and remove.
1.
2.
3.
ACCU
TRAC
®
INDICATION
EXPLANATION
DRYER
DISPLAY
Lower dryer motor sense circuit error on control board
or due to line interference (lower dryer cycles and lower
dryer display is disabled until diagnostic code is
Blocked coin 2 or coin drop control circuit failure (coin
recognition and price display is disabled while blockage
persists).
Upper dryer motor sense circuit error on control board
or due to line interference (upper dryer cycles and upper
dryer display is disabled until diagnostic code is
Lower dryer door sense error on control board or due to
line interference (lower dryer cycles and lower dryer
display is disabled until diagnostic code is manually
Upper dryer door sense error on control board or due to
line interference (upper dryer cycles and upper dryer
display is disabled until diagnostic code is manually
Lower dryer motor control circuit error (lower dryer
cycles and lower display is disabled until diagnostic
code is manually cleared).
Blocked coin 1 or coin drop control circuit failure (coin
recognition and price display is disabled while blockage
persists).
Voltage detected below 90vac for 8 seconds.
PN Models Only: Not receiving communications from
installed debit card reader in Enhanced (Generation 2)
Upper dryer motor control circuit error (upper dryer
cycles and upper dryer display is disabled until
diagnostic code is manually cleared).
cleared).
manually cleared).
manually cleared).
Debit mode.
cleared).
