October 2008
Page A-3
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Upper Controls, ANSI Models
ITEM PART NO. QTY DESCRIPTION
Fixed Control Box - ANSI
1 83059 1 with Fixed Cable, Serial #11211037 - up
2 91194 1 Strain Relief Washer
3 16120 1 Mounting Plate
4 REF 1 Cable, Fixed (see Wire Harness, Section F)
Removable Control Box - ANSI
5
– 1 with removable Cable, Serial #11211001 - 11211100
83051 1 with Removable Cable, Serial #11211101 - up
6 REF 1 Harness, Removable (see Wire Harness, Section F)
7 REF 1 Cable, Removable (see Wire Harness, Section F)
Fixed and Removable Control Box - ANSI
8 16242 1 Weldment, Control Box
9 13865 1 Bracket, Control Box Holder
10 6350 0.5 FT Tape, Foam
11 HDW5724 1 Screw, 5/16–18
12 13864 1 Bracket, Control Box Holder
13 HDW8294 1 Washer, Flat
14 8826 1 Thumb Screw, 5/16–18, Flower
15 6234 1 Switch, Toggle, Lift/Drive
16 6905 1 Switch, Toggle, Speed/Torque
17 7800 1 Switch, Emergency Stop
18
91159 1 Keyswitch
8082 1 Contact Block, NO
8083 1 Contact Block, NC
19 8044 1 Switch, Horn Button (Option)
20
91663 1 Matrix Module, Up to Serial # 11211036
91762 1 Matrix Module Serial # 11211037 - UP
21 HDW90879 2 Screw
22 HDW90803 2 Nut
23 90789 1 LED, Green, Drive Enabled (HD Models)
24 5694 1 Switch, Toggle (HD Models)
To Next Page
