October 2008
Page A-9
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Upper Control Joystick
ITEM PART NO. QTY DESCRIPTION
– – CONTROL ARM ASSEMBLY, JOYSTICK
1 8750 1 PIN (SERVICE ONLY)
2 8453 1 SWITCH ACTUATOR (SERVICE ONLY)
3 HDW8455 4 SCREW, 6-1/2" LG (SERVICE ONLY)
4 8752 1 GRIP-TOP HALF (SERVICE ONLY)
5 8751 1 GRIP-BOTTOM HALF (SERVICE ONLY)
6 13638 1 CONTROL ARM WITHOUT WIRE
7 8748 1 TRIGGER (SERVICE ONLY)
8 8456 1 ROCKER BOOT (SERVICE ONLY)
– 8761 – SWITCH ASSEMBLY (NOT SHOWN)
9 8447 1 SWITCH SEPARATOR(SERVICE ONLY)
10 8753 1 MOTION SWITCH, ON-OFF (SERVICE ONLY)
11 8448 2 SWITCH (SERVICE ONLY)
– 7476 5 AMP PINS
– 8089 1 FT WIRE, BLK 18GA 300 V
– 7777 2 TERMINAL, PUSH ON, 3/16"
– 8630 1 HANDLE, GRIP
