Mec 3072ES - Outrigger Installation (3772 ES HD

October 2008
Page F-17
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Outrigger Installation (3772ES HD)
ITEM PART NO. QTY DESCRIPTION
1 16279 1 Weldment, Outrigger Mount, Rear
2 HDW7938 16 Screw, 5/8–11 × 3" LG
3 HDW6633 16 Locknut, 5/8–11
4 21168 4 Weldment, Outer Outrigger
5 HDW7052 8 Screw, ½–13 × 3 ½" LG
6 HDW8498 4 Screw, ½–13 × 4"
7 HDW8457 20 Nut, ½–13
8
16258 1 Ladder, 3072RT W/Outriggers
16294 1 Ladder , 3772RT W/Outriggers
9 16278 1 Weldment, Outrigger Mount, Front
10 21170 4 Cover, Outrigger Cylinder
11 HDW6455 20 Screw, ¼–20 × ½"
12 HDW91328 4 Shoulder Screw, 5/8 × 4.75"
13 91278 4 Cylinder, Outrigger
14 90663 64 Spacer
15 10335 4 Tube, Inner Outrigger
16 HDW5916 4 Screw, ½–13 × 4.0"
17 20998 4 Bracket Pivot
18 HDW91395 4 Clevis Pin, 5/8 × 5.0"
19 HDW9219 4 Washer, Flat
20 HDW5920 4 Pin, Cotter, 1/8 × 1"
21 21002 4 Pad Weldment
