October 2008
Page B-13
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Control Cable / Horn Installation
ITEM PART NO. QTY DESCRIPTION
1 9716 1 HORN, 12-48V (option)
2 HDW5217 2 WASHER, FLAT, .343 ID × .688 OD × .063 THK
3 HDW6455 5 SCREW, ¼”-20, ½” LG, GR 5
4 5863 2 GROMMET, 1.5 ID × 1.75 OD × .187 THK
5 14604 1 COVER, TERMINAL STRIP
6 6964 1 CLAMP, CABLE, 1” DIA.
7 REF – CABLE, UPPER CONTROL
Items 8 – 10 installed on units Up to Serial # 11211141.
Replace with modular harness (ref page F-15)
8 6947 1 TERMINAL STRIP
9 HDW5363 3 SCREW, #6-32, 1” LG, GR 5
10 HDW5364 5 NUT, KEPS, #6-32 , GR 5
