Mec 3072ES - Upper Control Box Cover Assembly

October 2008
Page A-7
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Upper Control Box Cover Assembly
ITEM PART NO. QTY DESCRIPTION
– 13868 – Control Box Cover Assembly
1 13647 1 Control Arm
2 3772 1 Cover
3–––
4 7875 1 Gasket
5 7882 1 O-ring, 7/8" Id X 1 1/8" Od
6 HDW3768 1 Washer, Flat
7 1008348 1 Pin, Hold Down
8 HDW7887 1 Screw, #6-32, 1/2" Lg
9 13502 1 Bracket, Centering
10 3763 1 Spacer, Step
11 13402 1 Gear, Large
12 HDW8531 2 Washer, Flat
13 HDW7881 1 Washer, Bevel
14 3782 1 Cam. Directional
15 13403 1 Plate, Bottom
16 6917 1 Clamp, Cable 1/4"
17 7818 1 Bearing, Bronze, Flanged
18 HDW3771 1 Washer, Flat
19 5736 1 Ring, Retaining, 1/2"
20 HDW8399 4 Screw, #4 - 40, 5/8" Lg
21 8383 1 Potentiometer
22 HDW8567 2 Washer, Flat
23 8389 1 Gear, Spur
24 HDW7888 12 Screw, #10 - 32, 1/2" Lg
25 3764 2 Plate, Spacer
26 8696 2 Switch, Limit, Micro V7
27 3765 2 Plate, Strap
28 3766 1 Plate, Top
29 7819 1 Bearing, Bronze, Flanged
30 8435 1 Spring, Joystick, Centering
31 13527 1 Potentiometer Assembly (Includes 21, 22, & 23)
32 REF 1 Wire Harness (see Wire Harness, Section F)
