Mec 3072ES - Primary Machine Components Locator

"3072ES / 3772ES / 3772ES HD" Service & Parts Manual October 2008
Page VII
Component Service Section Parts Section
Platform Assembly
Upper Controls 2 | 4 | 5 A | F
Deck and Rails 3B
Chain Closure B
Optional Gate B
Extension Deck B
Control Terminal Strip B
Horn (optional) 2 A | B
Lift Assembly
Beams intro | 3 C
Maintenance Lock intro C
Lift Cylinders 1 | 3 | 4 | 5 C | E
Limit Switch 2 | 4 C
Base Assembly
Front Drive Motors intro | 1 | 3 | 4 | 5 D | E | F
R Drive Motors w/Brakes intro | 1 | 3 | 4 | 5 D | E | F
Steering Components 1 | 3 C | E | F
Steering Components 1 | 3 | 4 | 5 C | E | F
Wheels & Tires intro | 3 F
Hubs intro | 1 | 3 D | F
Slide Block intro | 3 C
Emergency Lowering 1 | 2 E | F
Hoses & Cables 1 | 2 | 3 | E | F
Outrigger (Option) 1 | 3 | 4 | 5 E | F
Power to Platform B | F
Power Module
Battery Pack intro | F
E-Lower Battery intro | F
Component Service Section Parts Section
Control Module
Lower Controls 2 | 3 | 4 | 5 A | F
Hydraulic Manifold 1 | 3 | 4 | 5 E | F
Hydraulic Pump 1 | 3 | 4 | 5 F
Hydraulic reservoir intro | 1 F
Hydraulic Filter intro | 1 F
Parking Brake Release 1 E | F
Emergency Lowering 1 E | F
Battery Disconnect 2 | 3 | 4 | 5 F
Battery Charger intro | 2 | 4 F
Outrigger Manifold 1 | 3 | 4 | 5 E | F
Electronic Control Modules
GP600 Motor Control intro | 2 | 4 F
GP400 Module intro | 2 | 4 F
GP400 Matrix Module intro | 2 | 4 A
PRIMARY MACHINE COMPONENTS LOCATOR
