October 2008
Page C-7
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly, 3072RT: Serial #11211100 - UP
… continued
ITEM PART NO. QTY DESCRIPTION
1 40448 1 Beam, 6x8x.250 TS w/pins
2 17070 1 Beam, 6x8x.313 w/pins
3 40081 1 Beam, 6x8x.313 w/pins
4 17071 1 Beam, 6x8x.250 BF w/pins
5 40447 1 Beam, 6x8x.250 TF w/Bearings
6 17067 1 Beam, 6x6x.312 bored
7 40083 1 Beam, 6x6x.312 bored
8 17065 1 Beam, 6x8x.250 BS w/Bearings
9 14990 1 Maintenance Lock Weldment
10 8675 1 Bearing, 2 ¼" × 2" × 1 ½" LG
11 13175 16 Washer, Nylon 2.062 ID × 2.620 OD × .030 THK
12 6701 12 Ring, Retaining, 2"
13 25429 12 Spacer Block - Beams
To Next Page
