October 2008
Page D-7
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Wheel Motor, Rear
ITEM PART NO. QTY DESCRIPTION
–
91319
– Wheel Motor W/brake
1
9781
– Seal Kit
1a – 1 Dust Seal
1b – 1 Metal Backup Shim
1c – 1 Backup Seal
1d – 1 Shaft S eal
1e – 1 Small Piston O-ring Seal
1f – 1 Small Piston Seal
1g – 1 Large Piston O-ring Seal
1h – 1 Large Piston Seal
1i – 1 O-ring Seal
1j – 3 Body Seal
1k – 1 Manifold Seal
1l – 1 Commutator Seal
1m – 1 O-ring Seal
1n – 1 Backup Seal
2
91138
– Disk Kit
2a – 10 Friction Disk
2b – 9 Disk Stamping
2c – 2 Thick Disk Stamping
To Next Page
