October 2008
Page A-5
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Upper Controls, CE Models
ITEM PART NO. QTY DESCRIPTION
1 90873 1 With Removable Cable
2 REF 1 Cable, Removable(See Wire Harness, Section F)
3 REF 1 Harness, Removable(See Wire Harness, Section F)
4
9183 1 Lens, Red, Overload Indicator
9188 1 Light, Bayonet, 14 Volt
9179 1 Socket, Indicator Light
5 7553 1 Alarm, Overload Warning
6 16242 1 Weldment, Control Box
7 13865 1 Bracket, Control Box Holder
8 6350 0.5 FT Tape, Foam
9 HDW5724 1 Screw, 5/16–18
10 13864 1 Bracket, Control Box Holder
11 HDW8294 1 Washer, Flat
12 8826 1 Thumb Screw, 5/16–18, Flower
13 6234 1 Switch, Toggle, Lift/Drive
14 6905 1 Switch, Toggle, Speed/Torque
15 7800 1 Switch, Emergency Stop
16
91159 1 Keyswitch
8082 1 Contact Block, NO
8083 1 Contact Block, Nc
17 8044 1 Switch, Horn Button (Option)
18
91663 1 Matrix Module, Up to Serial # 11211036
91762 1 Matrix Module Serial # 11211037 - UP
19 HDW90879 2 Screw
20 HDW90803 2 Nut
21 90789 1 LED, Green, Drive Enabled (HD Models)
22 5694 1 Switch, Toggle (HD Models)
To Next Page
