“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hydraulic Hoses - Pump and Return
… continued
ITEM PART NO. QTY DESCRIPTION
11 6458 as req Return Line, Cut to Length
19 91466 1 TEE
20 91468 1 Reducer
21 9920 1 TEE
22 90315 1 Hose Assy
23 91698 1 Hose Assy
24 91247 6 FT Hose Assy, ¾", 12LOLA bulk
25 HDW91246 2 Fitting Female ¾" JIC Male ¾" Hose Barb
26 91265 1 Hose Assy, 1" × 22", (16GMV-16FJX-16FJX-22")
27 23689 1 Hose Assembly
28 9029 1 Hose Assembly, 3772ES Only
29
90985 1 Hose Assembly, 3072ES Lift Cylinder
9039 1 Hose Assembly, 3772ES Lower Lift Cylinder
30 91719 1 Hose Assembly, 3772ES Upper Lif t Cylinder
31 7391 1 TEE, 3772ES Only
