October 2008
Page B-5
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Rollout Lock Pin Assembly
ITEM PART NO. QTY DESCRIPTION
1 13737 1 Pin, Extension Lock
2 7184 3.7 FT Cable, Coated And Rolled
3 8814 2 Sleeve, Aluminum Oval
4 14344 1 Handle
5 HDW8303 1 Screw, 5/16" - 18, 2" LG
6 HDW8304 1 Locknut, 5/16" - 18
7 7408 1 Spring, Deck Lock
8 HDW7031 1 Washer, Flat, ½" ID 7/8" OD
9 HDW8513 1 Pin, Spring, 1/8" DIA. ¾" LG
