Mec 3072ES - Wire Harness

October 2008
Page F-15
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Wire Harness
ITEM PART NO. QTY DESCRIPTION
1 91671 1 Harness, Main –Control Module - Base & Valves]
2 91069 1 Harness, Lift Cylinder Down Valve (3072ES) - Control Module to Lift Cylinder]
3 91085 1 Harness, Lower Lift Cylinder Down Valve (3772ES) - Control Module to Lift Cylinder]
4 91086 1 Harness, Upper Lift Cylinder Down Valve (3772ES) - Control Module to Lift Cylinder]
5 91672 1 Harness, Lower Controls - Inside Control Module]
6 91759 1 Cable, Battery to Master Disconnect
7 91760 1 Cable, Chassis Ground
8 6208 8 Cable, Battery, 8 Inch
9 91674 1 Harness, E-Down with Diode to Batteries (3772ES)
10 8346 1 Harness, Joystick
11
91758 1 Harness, Upper Controls, Removable - Up To Serial # 11211039
91761 1 Harness, Upper Controls, Removable - Serial # 11211040 – Up
12 – – –
13 91780 1 Cable, Upper Controls, Removable
14
91757 1 Control Cable, 3072ES
91756 1 Control Cable, 3772ES
– 91678 1 Harness, 2wd Disconnect, Limit Switch (not shown)
– 9411 1 Power to Platform (not shown)
– 91677 1 Harness, Outrigger (not shown)
