October 2008
Page D-5
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Front Axle Assembly
ITEM PART NO. QTY DESCRIPTION
1 HDW5920 2 Pin, Cotter, .12 DIA. X 1” LG
2 HDW90770 2 Pin, Clevis, ½ DIA. X 1 3/8” LG
3
91019 2 Cylinder, Steering
90990 – Seal Kit, Steer Cylinder (not shown)
4 91263 4 Hose Assembly ½" (8M3K-8FJX-8FJX90S-37")
5 HDW7326 2 Screw, 5/8” - 11. 4” LG, GR 5
6 HDW9219 4 Washer, .656 ID X 1.312 OD X .093 THK
7 7292 2 Bearing, Sleeve, Bronze
8 HDW8568 6 Nut, 1 1/8” - 18
9 20311 4 Washer, 1.375 ID X 2.75 OD X .250 THK
10 – – –
11 20312 8 Washer, Thrust
12 90282 1 Hose Assembly 5/16" (Not Shown)
13 HDW7043 8 Screw, ½”-13, 2.50” LG, GR 8, Socket Head
14 7300P 2 Motor, Wheel, Hyd.
15 90765 8 Hose Protection (Not Shown)
16
40464 1 Mount, Wheel Motor, LH, FRONT (cast 40463)
40308 1 Mount, Wheel Motor, RH, FRONT (cast 40367)
17 HDW6633 2 Nut, Lock, 5/8” - 11, GR 5
18 40334 4 Mount, Motor W/Bearings
18a 9307 4 Bearing, 1.50 x 1.0 DIA
19 9607 2 Fitting, Grease, 90°
20 HDW5994 16 washer, lock, .640 ID X 1.050 OD X .165 THK
21 HDW90410 16 Screw, 5/8” - 11, 2” LG, GR 8, Socket Head
22 HDW8457 8 Nut, ½”-13, GR8
23 10709 2 Hub
24
91165 1 Wheel/tire Assy, RH - 10 PLY - PNEUMATIC (ANSI standard)
91167 1 Wheel/tire Assy, RH - 10 PLY - FOAM (ANSI option) (CE standard)
91166 1 Wheel/tire Assy, LH - 10 PLY - PNEUMATIC (ANSI standard)
91168 1 Wheel/tire Assy, LH - 10 PLY - FOAM (ANSI option) (CE standard)
25 HDW5290 6 Pin, Cotter, .156 DIA. X 1.75” LG
26 HDW6677 12 Nut, Lug, ½” - 20, GR 5
27 – – –
28 14331 1 Rod, Tie Steering
29 HDW8984 4 Fitting, MB-MJ-12-8
30 HDW91236 2 Fitting, MB-MJ90-4-5
