“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Rear Axle Assembly
ITEM PART NO. QTY DESCRIPTION
1 40258 2 Mount, Motor, Rear Axle, Machined
2 HDW5994 20 Washer, Lock, .640 ID X 1.050 OD X .165 THK
3 HDW90409 12 Bolt, 5/8” - 11, 1 ½” LG
4 6633 4 Nut, 5/8” - 11
5–––
6–––
7–––
8 90765 4 Hose Protection (not shown)
9 91319 2 Wheel Motor, Hyd W/brake
10 HDW5989 8 Screw, 5/8”-11, 2.25” LG, GR 5
11 14773 2 Hub
12
91165 1 Wheel/tire Assy, RH - 10 PLY - PNEUMATIC (ANSI standard)
91167 1 Wheel/tire Assy, RH - 10 PLY - FOAM (ANSI option) (CE standard)
91166 1 Wheel/tire Assy, LH - 10 PLY - PNEUMATIC (ANSI standard)
91168 1 Wheel/tire Assy, LH - 10 PLY - FOAM (ANSI option) (CE standard)
91180 – Wheel (service)
91181 – Tire 26x12.00-380 (service)
13 HDW9037 – Nut, Castle, M42 X 3 (service)
14 HDW6677 12 Nut, Lug, ½” - 20, GR 5
15 8925 2 Pin, Cotter, .250 DIA. X 3" LG
16 HDW8984 4 Fitting, MB-MJ-12-8
17 HDW91235 2 Fitting, MB-MJ45-4-5
18 HDW8881 2 Fitting, MB-MJ-4-4
19 91585 2 Valve, Solenoid Assembly
20
91464 2 Valve, nc poppet
91141 2 Coil, 12V Deutsch
21 16348 2 Cover, Upper Control Valve Shield
22 16349 2 Cover, Lower Control Valve Shield
To Next Page
