Mec 3072ES - Scissor Assembly, 3772 RT: up to Serial #11211099

October 2008
Page C-5
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly, 3772RT: Up to Serial #11211099
ITEM PART NO. QTY DESCRIPTION
1 16290 1 Beam 6 ×6 ×.188
2 14487 2 Block, Slide, Platform
3 HDW5217 8 Washer, Flat, .343 ID × .688 OD × .063THK
4 HDW8303 8 Screw, 5/16" - 18, 2.00" LG
5 HDW8294 8 Washer, Flat, .328 ID × 1.000 OD × .100 THK
6 HDW8304 8 Nut, 5/16 - 18
7 40124 1 Beam 6 × 6 × .250
8 16289 1 Beam 6 ×6 ×.188
9 30407 1 Pin 2.00 DIA × 25.90" LG
10 16292 1 Beam 6 × 6 ×.375 W/Bearings
11 91314 1 Lift Cylinder, Lower
12 25429 16 Spacer Block - Beams
13 16285 1 Beam 6 × 6 ×.375, Bottom Fitted
14 90235 2 Wear Pad, Anle, S lide Block, Top
15 40306 2 Slide Pivot Lower Cast Machined
16 7160 2 Bearing, 1 ¾" × 2" - 28DU32
17 5432 4 Grease Fitting
18 9587 2 Wear pad, Slide block, Bottom
19
16286 1 Beam 6 ×6 ×.188
6669 2 Bearing, 2.0 × 2.0 - 32DU32
20
40106 1 Beam 6 ×6 ×.375
6669 2 Bearing, 2.0 × 2.0 - 32DU32
21
16284 1 Beam 6 ×6 ×.375
6669 2 Bearing, 2.0 × 2.0 - 32DU32
22 40459 2 Casting, Machined, Lower Pivot
23 6669 2 Bearing, 2.0 × 2.0 - 32DU32
24 HDW6491 6 Washer, Flat, .562 ID × 1.375 OD × .109 THK
25 HDW8284 6 Bolt, ½" - 13, 2.00" LG GR8
26 HDW8457 6 Locknut, ½" - 13, GR8
27 16287 1 Beam 6 × 6 ×.188 W/Pins
28 HDW8899 4 Ring, Retaining (not shown)
29 16288 1 Beam 6 × 6 ×.250 w/Bearings
30 16282 1 Support Beam W/Bearings
31 30518 1 Maintenance Lock Weldment
32 8675 1 Bearing, 2 ¼" × 2" × 1 ½" LG (not shown)
33 91315 1 Lift Cylinder, Upper
34 HDW6455 8 Screw, ¼" - 20, ½" LG
35 14538 4 Bracket, Cylinder Retaining
36 14806 1 Support Beam Weldment
37 16283 4 Mount cylinder w/Cap
38 14537 4 Pin, Cylinder Mount, 1.998 × 6.408
39 6701 15 Ring, Retaining, 2" Shaft
40 14488 2 Block, Slide Platform
41 HDW13175 29 Washer, 2.062 ID × 2.620 OD × .030 THK (not shown)
