October 2008
Page E-25
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Steering Cylinder
ITEM PART NO. QTY DESCRIPTION
– 91019 2 Steering Cylinder
1 HDW8881 1 Adapter Male ¼" O-Ring-Male ¼" JIC
2 HDW8876 1 Adapter Male ¼ O-Ring-Male ¼" JIC TEE
3 HDW5925 1 Jamnut 5/8-18
4 7293 1 Rod End
– 90990 REF S eal Kit (Service)
