“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Lift Cylinder, Lower, 3772
ITEM PART NO. QTY DESCRIPTION
1 91314 1 Cylinder, Lower lift, 3772RT
2 9039 1 Hose Assembly, Lift Cylinder 3/8"
3 HDW7601 1 Fitting, Elbow 90°, .37JIC × 37 O-ring
4 91804 1 Orifice, 0.042
5 90993 4 Bearing, Bronze, 2" ID × 2" LG
6 91462 1 Valve, 2 Way, N.C. Poppet Dual Coil
7–––
8 HDW6727 1 Fitting, Pipe 90°, Male Barb
9 HDW8152 2 Screw, ¼" - 20 × ¾" LG
10 – – –
11 16062 1 Bracket, Lift Cylinder Valve Guard
12 6458 21 FT Hose, Return Line
13 – – –
14 7788 1 Clamp, Hose, 5/8 Max
15 90969 1 Relief Valve
16 91141 2 COIL, 12 VOLT, Deutsch Connector w/Diode
17 HDW90943 1 Fitting, TEE Adaptor
18 HDW90945 2 Fitting, Female Swivel
– 90988 REF Kit, Seal-Lift Cylinder - Lower (Service)
