Mec 3072ES - Scissor Assembly, 3072 RT: up to Serial #11211099

October 2008
Page C-3
“3072ES / 3772ES / 3772ES HD” Service and Parts Manual
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Scissor Assembly, 3072RT: Up to Serial #11211099
ITEM PART NO. QTY DESCRIPTION
1 14488 2 Block, Slide, Platform
2 40448 1 Beam, 6 × 8 × .250, Top Slide, W/pins
3 40084 1 Beam, 6 × 8 × .313 W/pins
4 40081 1 Beam, 6 × 8 × .313 W/pins
5 40444 1 Beam, 6 × 8 × .250, Bottom Fixed, W/pins
6 40459 2 Lower Pivot, Machined Casting
6a 6669 2 Bearing, 2" × 2"
7 5432 4 Grease Fitting
8 HDW8457 6 Locknut, ½" - 13, GR B
9 HDW8284 6 Screw, ½" - 13, 2" LG, GR 8
10 HDW8899 2 Ring, Retaining (Not Shown)
11 14538 2 Bracket, Cylinder Retaining
12 HDW6455 4 Screw, ¼" - 20, ½" LG
13 14537 2 Pin, Cylinder Mount
14 – – –
15 – – –
16 – – –
17 6701 10 Ring, Retaining, 2"
18 9587 2 Wear Pad, Slide Block, Bottom
19 90235 2 Wear Pad, Angle, Slide Block Top
20
40306 2 Slide Pvt, Lwr Cast, Machined
8785 .67 FT Tape, Double Coated
21 7160 2 Bearing, 1 ¾" × 2"
22 40446 1 Beam, 6 × 8 × .250, Bottom Slide, W/bearings
23 14990 1 Maintenance Lock Weldment
24 8675 1 Bearing, 2 ¼" × 2" × 1 ½" LG (not shown)
25 25429 12 Spacer Block - Beams
26 91020 1 Lift Cylinder
27
40083 2 Beam, 6 × 6 × .313
6669 4 Bearing, 2" × 2" (Not Shown)
28 14806 1 Support Beam Weldment
29 16283 2 Cylinder Mount
30 HDW8303 8 Screw, 5/16" - 18, 2" LG
31 HDW5217 8 Washer, Flat, .343 ID × .688 OD × .063 THK
32 HDW8294 8 Washer, Flat, .328 ID × 1.000 OD × .100 THK
33 HDW8304 8 Nut, 5/6" - 18
34 14487 2 Block, Slide, Platform
35 40447 1 Beam, 6 × 8 × .250, Top Fixed, W/bearings
36 HDW13175 16 Washer, 2.062 ID × 2.620 OD × .030 THK (not shown)
